19
Safety
Precautions
Installation
Requirements
Installation
Instructions
2. Attach copper tubing to the manual shutoff valve.
ab
a Pr
ef
err
ed L
oca
tions
b Optional Locations
3. Slowly feed the copper tubing through the hole into the opening.
Continue feeding the tubing, until there is enough length to connect to
the inlet (front, left-hand side of the dishwasher) yet remain within the
required boundary.
a
3" to 4
¾
"
(7.6 cm to 12.1 cm)
a
Copper Tubing
PREPARE TO CONNECT DRAIN HOSE
The drain hose will be connected to the house drain sys
tem after the
dishwasher is installed in the opening.
1. Drill a 1
" (3.8 cm) hole in cabinet wall or floor on the side of th
opening closest to the sink.
NOTE: You can tap
e the hose to the floor to secure it while dishwasher is
moved into place.
4. Slowly turn water shuto˜ v alve to “ON” position. Flush water into a
shallow pan to get rid of particles that may clog the inlet valve.
5. Turn shuto˜ v alve to “OFF” position.
To Next Page
