Midea R410A T3 50Hz Top-discharge Series MCAC-UTSM-201707
109
Correct install the back cover and firmly buckle the front cover and back over, otherwise will
make the front cover drop off.
7. Wired remote controller initial parameter setting:
Change the related functions of the controller through adjusting the initial parameters.
The wired controller initial parameter includes two codes “XY”. The first code “X” means
the function class, the second code “Y” means detailed configuration of this function.
Setting method:
Step1: Simultaneously press the mode button and fan speed button of the wired
controller for 5 seconds to enter the parameter setting state.
Step2: The value of the first code “X” is “0”, press the temperature setting buttons and
to adjust the second code value.
Step3: After setting the second code value, press Quiet/OK button to switch the first
code to the next value.
Step4: When the first code value is “6”, press Quiet/OK button again to exit the
parameters setting.
