Midea MV6-R450WV2GN1 Service Manual

V6R VRF 50/60Hz
52
Midea
V6R Series Service Manual
1 Outdoor Unit Field Settings
1.1 PCB Switches and Switch Settings
Figure 4-1.1: Outdoor unit main PCB switches
Table 4-1.1: Outdoor unit main PCB switch settings
Switch
Setting
Switch positions
1
Description
S4
Static pressure
Standard static pressure (default, 0Pa)
Low static pressure mode (20Pa)
Medium static pressure mode (40Pa)
High static pressure mode (60Pa)
Super high static pressure mode (80Pa)
S6-1
Reserved
Reserved
S6-2
Continuous
heating
2
Only reverse cycle defrosting is allowed (default)
Continuous heating and reverse cycle defrosting are allowed
S6-3
Reserved
Reserved
S7
Reserved
Reserved
Table continued on next page …
S7 S5 ENC2 ENC1 S4 S9 ENC5
S13 S8 S6 S10 S12 ENC3 ENC4
