Midea UR-BCD280WE-DQ - Product Specification; Type Specification(None); Electrical Parameters; Inside Temperature

Service Manual, 2016-12
14 / 46
5.Product specification
5.1 type specification(None)
5.2 Electrical parameters
Product Name
UR-BCD280WE-DQ
UR-BCD280WE-DQ
UR-BCD280WE-SQ
Product Code
22031020000145
22031020001522
22031020000146
Name
Item
Type
Specification
Specification
Specification
Compressor
Compressor
/
EZ80E1C
EZ80H1A-USCL
EZ80H1Z
Starter
PTC
QP2-4R7
QP2-4R7
QPE2-A4R7MD3
Overload protector
OLP
DRB31T61A1
DRB31T61A1
DRB31T61A1
Winding resistance of
compressor wiring
terminal
Rmc:10-20Ω
Rsc:30-50Ω
Rms=Rmc+Rsc
Rmc:10-20Ω
Rsc:30-50Ω
Rms=Rmc+Rsc
Rmc:10-20Ω
Rsc:30-50Ω
Rms=Rmc+Rsc
Variable frequency
driver board
/
/
/
/
Motor
Fan motor of the
freezing chamber
BLDC
DC12V/≤4W
DC12V/≤4W
DC12V/≤4W
Ventilation door of the
refrigerating chamber
/
/
/
/
Condensation fan
/
/
/
/
Lights inside
the refrigerator
Lights inside the
freezing chamber
/
/
/
/
Lights inside the
refrigerating chamber
LED
115V/＜3.5W
115V/＜3.5W
115V/＜3.5W
Switch of the
refrigerator door
mechanicalsw
itch
sector
sector
sector
5.3Inside temperature
Temperature tolerance ≤ 2
o
C
Compartment
The highest (
o
C)
Lowest (
o
C)
Freezing
-14
-24
Refrigerating
9
1
Variable temperature
/
/
5.4Defrosting parts
Defrosting period
Initial defrosting period
Normal defrosting period
Temperature is lower than 0
o
C
6~24 hours
Defrosting sensor
NTC
B3839
