Midland MXT115 User Manual

Page 21
midlandusa.com
Model MXT115
Page 20
midlandusa.com
Model MXT115
6. When the desired Privacy Code is shown on the LCD display, press the
Monitor/Scan / to conrm your selection. YOU MUST PRESS THE
Monitor/Scan BUTTON TO CONFIRM YOUR SELECTION OR THE PRIVACY CODE
WILL NOT BE CHANGED
NOTE: If you select a CTCSS Privacy Code, any pre-selected DCS
Privacy Code will be cancelled, and vice-versa.
Selecting the Transmit (TX) Power Level
The MXT115 provides two transmit power levels; HI and Lo. the Lo power
level is generally suitable when operating under optimum conditions (see
About Range). The HI power level is recommended to ensure you get
maximum range from your radio.
To adjust the Transmit Power Level:
1. Press and release the Menu button to place the radio in “Menu”
mode.
2. Use the Channel Up or Channel Down buttons to scroll the
menu options until the LCD display shows Pr
3. Press the Monitor/Scan / button to conrm your selection.
4. Use the Channel Up or Channel Down button to toggle the
transmit power setting between HI and Lo.
5. When the desired transmit power level is shown on the LCD display,
press the Monitor/Scan / button to conrm your selection.
YOU
MUST PRESS THE MONITOR/SCAN BUTTON TO CONFIRM YOUR SELECTION
OR THE POWER LEVEL WILL NOT BE CHANGED.
Note: Due to output power regulations channels 1 through 7 cannot be
removed from the Lo transmit power setting.
Adjusting Squelch Sensitivity
The MXT115 has adjustable squelch sensitivity. The minimum squelch
level of 00 is the most sensitive, which allows the squelch to open on very
weak signals. Setting the squelch to the maximum setting of 09 requires
very strong signals to open the squelch.
To adjust the Squelch Sensitivity:
1. Press the Menu button to place the radio in “Menu” mode.
2. Use the Channel Up or Channel Down button to scroll through
the menu options until the LCD display shows Sq.
3. Press the Monitor/Scan / button to conrm your selection
4. Use the Channel Up or Channel Down button to scroll forward
or backward to select the desired squelch level, from oF to 09.
▪ The default squelch setting is 04, which generally provides reliable
squelch operation for most applications.
5. When the desired squelch level is shown on the LCD display, press
the Monitor/Scan / button to conrm your selection. YOU MUST
PRESS THE MONITOR/SCAN BUTTON TO CONFIRM YOUR SELECTION OR THE
SQUELCH SENSITIVITY WILL NOT BE CHANGED.
Roger Beep
When the PTT button on the mic is released, the radio will beep to conrm
to other users that your transmission is complete
To Activate the Roger Beep:
1. Press and release the Menu button to place the radio in “Menu”
mode.
2. Use the Channel Up or Channel Down button to scroll through
the menu options until the LCD display shows rb.
3. Press the Monitor/Scan / button to conrm your selection.
4. Use the Channel Up Channel Down button to select ON or OFF.
5. When the desired selection is shown in the LCD display press the Mon-
itor/Scan / button to conrm your selection.
YOU MUST PRESS
THE MONITOR/SCAN BUTTON TO CONFIRM YOUR SELECTION OR THE ROGER
BEEP WILL NOT BE CHANGED.

Midland MXT115 Specifications

General

Rated power	15 W
Product type	Speaker/microphone
Compatibility	Midland FRS/GMRS radios
Product color	Black
Brand compatibility	Midland
Quantity	1
Package type	Box
Package depth	101.6 mm
Package width	254 mm
Package height	304.8 mm
Package weight	1133.98 g

Weight and Dimensions

Depth	127 mm
Width	133.35 mm
Height	25.4 mm
Weight	467.2 g
