SPECIFICATIONS
Channels:
Privacy Codes:
Operating Frequency:
Repeater Frequency:
Power Source:
15 GMRS Channels and
10 NOAA Weather Channels
38 CTCSS; 104 DCS
UHF; 462.5500 ~ 462.725 MHz
UHF; 467.5500 ~ 467.725 MHz
13.8 VDC Nominal
GMRS Frequency Chart
Ch. No. Ch. Freq. (MHz) Ch. No. Ch. Freq. (MHz)
1 462.5625 15 462.550
2 462.5875 16 462.575
3 462.6125 17 462.600
4 462.6375 18 462
5 462.6625 19 462.650
6 462.6875 20 462.675
7 462.7125 21 462.700
Ch 8 ~ 14 Reserved for FRS 22 462.725
WX Band Channels
.625
162.550
162.400
162.475
162.425
162.450
162.500
162.525
161.650
161.775
163.275
1
2
3
4
5
6
7
8
9
10
Channel Number Frequency (MHz)
CTCSS Privacy Codes Frequency Chart
Code Freq. Code Freq. Code Freq. Code Freq Code Freq
1 67.0 9 9
9
1.5 17 118.8
.8
25 156.7 33 210.7
2 71.9 10
.8
18 123.0 26 162.2 34 218.1
3 74.4 11 97.4 19 127.3 27 167.9 35 225.7
4
4
77.0 12 100.0 20 131.8 28 173.8 36 233.6
5 79.7 13 103.5 21 136.5 29 179.9 37 241.8
6 82.5 14 107.2 22 141.3 30 186.2 38 250.3
7 85.4 15 110.9 23 146.2 31 192
8 88.5 16 114.8 24 151.4 32 203.5
9
DCS Privacy Codes Chart
No. Code No. Code No. Code No. Code
1 23 27 165 53 413 79 731
2 25 28 172 54 423 80 732
3 26 29 174 55 431 81 734
4 31 30 205 56 432 82 743
5 32 31 223 57 445 83 754
6 43 32 226 58 464 84 36
7 47 33 243 59 465 85 53
8 51 34 244 60 466 86 122
9 54 35 245 61 503 87 145
10 65 36 251 62 506 88
2
12
11 71 37 261 63 516 89
2
25
12 72 38 263 64 532 90
2
46
13 73 39 265 65 546 91
2
52
14 74 40 271 66 565 92
2
55
15 114 41 306 67 606 93 266
16 115 42 311 68 612 94 274
17 116 43 315 69 624 95 325
18 125 44 331 70 627 96 332
19 131 45 343 71 631 97 356
20 132 46 346 72 632 98 446
21 134 47 351 73 654 99 452
22 143 48 364 74 662 100
4
54
23 152 49 365 75 664 101
4
55
24 155 50 371 76 703 102
4
62
25 156 51 411 77 712 103
5
23
26 162 52 412 78 723 104 526
Ch. Number TX Freq. (MHz) RX Freq. MHz)
15RP 467.5500 462.5500
16RP 467.5750 462.5750
17RP 467.6000 462.6000
18RP 467.6250 462.6250
19RP 467.6500 462.6500
20RP 467.6750 462.6750
21RP 467.7000 462.7000
22RP 467.7250 462.7250
GMRS Repeater Channels

Midland MXT115 Specifications

General

Rated power	15 W
Product type	Speaker/microphone
Compatibility	Midland FRS/GMRS radios
Product color	Black
Brand compatibility	Midland
Quantity	1
Package type	Box
Package depth	101.6 mm
Package width	254 mm
Package height	304.8 mm
Package weight	1133.98 g

Weight and Dimensions

Depth	127 mm
Width	133.35 mm
Height	25.4 mm
Weight	467.2 g
