Midmark Preva - System Configuration Mode

Preva Dental X-ray System User Manual, 00-02-1576, Revision ZA1
29
About System
Configuration
Mode
The System has a software-driven configuration mode. These procedures can
be performed in configuration mode.
• Adjusting the display
• Changing default exposure settings
• Changing the cone size
• Showing current system configuration
• Displaying diagnostic data
Using System
Configuration
Mode
1. To enter system configuration mode, depress the Tooth Selection and
Patient Size Selection buttons on the Operator Panel simultaneously for
five seconds. The Main System Configuration menu will appear, as shown
in
Figure 4. The Ready Indicator will blink.
2. To make a selection from the menu, use the up and down arrows to
highlight an option. Select the option by pressing the right arrow.
3. After selecting an option, use the up and down arrows to increase or
decrease values.
Figure 4
Main System
Configuration Menu
System Configuration Mode
