Diode Test Results
Decision Action
EXCESSIVE
RIPPLE
One or more diodes in the alternator are not functioning or there is stator damage, which is
shown by an excessive amount of AC ripple current supplied to the battery.
√ Make sure the alternator mounting is sturdy and that the
belts are in good shape and functioning properly. If the
mounting and belts are good, replace the alternator.
OPEN PHASE
Replace the alternator.
OPEN DIODE
SHORTED DIODE
Decision Color Example 500 Rated
Good Battery
= 450 measured
Good Recharge
= 250 measured
Charge and Retest
N/A
Replace Battery
= 150 measured
Badcell, Replace
= 0 measured
The circle size is based on a (calculated) charged battery condition.
