Midtronics CPX-950 EU User Manual

CPX-950
www.midtronicseurope.com
Midtronics BV Hoofdveste 6-8 3992DG Houten
10
11
2 – 12V Battery
3 - 24V System
CPX-950
Test Results - Bat..
VIN: 12345
Good Baery
Rated 575 CCA
Voltage 12.72 V
Type 599 CCA
Temperature: 20°C
Send Results
Done
Temperature is only shown when the temperature question was asked.
Test Results - Bat...
Testcode: 123456-7890123
Send Results
Done
Test Results - Bat...
Cranking Health
Baery meets or exceeds
required standards. Test
again in 90 days or at
next service opportunity.
Rated: 575 CCA
Measured: 599 CCA
Test Results - Battery Test
To send the test results select Send Results. To return to the Home Screen, select Done to
continue to the mainscreen.
Refer to Appendix B: Decision Tables for a complete explaination of the possible test results.
24V System
Use 24V System Test to test and verify the condition of customer
batteries for possible return and/or warranty claim.
Press  to return to the previous screen, select options and
when necessary, O to enter or continue to the next step. Use BACK to
return to the Main Menu.
Battery Test
1. First select whether you wish to perform a battery test or generate a battery pair. For generate
pair test instructions, see next page.
2. Connect to the (rst) battery.
3. Battery Test Setup - Edit the displayed battery information.
Battery Type SLI AGM
Number of Batteries 1 2
Battery Units EN
SAE
IEC
DIN
EN2
JIS
Battery Rating
Hold down  or  to increase scrolling
speed.
VIN Insert the last 5 number of the Vehicle ID
number (VIN). This step is optional.
Rating Description Range
EN European Norms. The battery is required to meet a
voltage of 7.5V after 10 seconds
100 to 3000
SAE Society of Automotive Engineers norm. The test
species that the battery at a temperature of –18°C
will deliver a current equal to the Cold Cranking
Amps for 30 seconds with the voltage staying
above 7.2 volts
100 to 3000
IEC International Electrotechnical Commission norm.
The IEC test is performed at -18°C
100 to 1000
DIN Deutsche Industrie-Norm 100 to 1000
EN2 European Norms 2. Performing a different second
discharge than with EN.
100 to 3000
JIS Japanese Industrial Standard test, carried out at
-15°C.
A list is shown
Select Start to advance to the test.
4. Temperature - you are requested to aim the temperature sensor at the battery. Then click 'Cap-
ture' The test is started.
3 - 24V System
