CPX-950
www.midtronicseurope.com
Midtronics BV Hoofdveste 6-8 3992DG Houten
14
15
3 - 24V System
3 - 24V System
CPX-950
Test Results - Bat. 1
1
Good Baery
Rated 575 CCA
Voltage 12.72 V
Measured 599 CCA
Baery Type: SLI
Temperature: 24 C
Send Results Done
Test Results - Battery Test
To send the test results select Send Results. To continue to further testing the 24V batteries, select
System Test. To return to the Home Screen, select Done
to return to the main screen.
(In Vehicle test) - 24V System Test
1. Select External Amp Clamp or No Amp Clamp. Midtronics recommends to use the PDF40
external amp clamp.
2. Start the vehicle's engine and leave it running.
3. Ensure all accessories (High Beam headlights/ventilation blower etc.) are o and select Next.
The analyzer tests the alternator output.
4. When prompted, rev and hold the engine to between 1000 to 1250 rpm.
The analyzer tests the alternator output again.
5. When prompted Idle the engine and and select Next.
6. Turn on the high beam headlights and ventilation blower.
7. Select Next.
The analyzer tests the alternator output.
8. When prompted, rev and hold the engine to between 1000 to 1250 rpm.
The analyzer tests the alternator output again.
9. When prompted Idle the engine, turn o loads, then turn o ingition and select Next.
10. If an external amp clamp was used, the tester now asks the measured drain current. Insert the
number, then select Next.
11. The results are shown.
System Test Results
Test Results - Summary
Good Baery
Cranking Normal
Charging Normal
Send Results Done
Test Results - Summary
The Test Results - Summary screen is displayed following a System Test. Select the Battery,
Cranking, or Alternator Test to view detailed test results for each part of the test.
Refer to Appendix
B: Decision Tables for a complete explaination of the possible test results.
To send the test results to a congured printer or via email select Send Results. To return to the
Home Screen, select Done
to the Main Menu
