EXP-803 Chapter 3: Battery Test
The Battery Test analyzes a battery not connected to
a vehicle. The tester guides you through the steps of
selecting your battery test parameters and interpret-
ing the results. Before you start the test, review the
instructions in “Test Preparation” section in the previ-
ous chapter.
IMPORTANT: When you start a new test, the last test
results in memory are overwritten. Remember to re-
cord or print the results if you need to retain them.
If you use the ARROW keys to select option buttons, press
NEXT to continue to the next step.
1. In the Main Menu select the Battery Test icon.
2. Use or to select the location of the battery and press
NEXT to continue. This option is skipped when perform-
ing a System Test.
1 OUT OF VEHICLE
2 IN VEHICLE (connected to vehicle)
Press NEXT to continue.
3. Use or to select the POST TYPE and press NEXT to
continue.
1 TOP POST
2 SIDE POST
3 JUMP START POST (System Test only)
Press NEXT to continue.
4. Use or to select the APPLICATION and press NEXT
to continue.
1 AUTOMOTIVE (default)
2 MARINE BATTERY
3 MOTORCYCLE
4 TRUCK/GROUP 31
5 COMMERCIAL_4D/8D
6 LAWN & GARDEN
Press NEXT to continue.
If you select MOTORCYCLE as the battery type, the
analyzer asks for the battery part number. Scroll to the
part number (128 available). To increase your scrolling
speed, hold the or key, or use or to move up or
down four part numbers at a time.
5. Use or to select the BATTERY TYPE and press NEXT
to continue.
1 REGULAR FLOODED
2 AGM
3 AGM SPIRAL
4 GEL
Press NEXT to continue.
6. Use or to select the battery RATING UNITS and press
NEXT to continue. The rating units and rating informa-
tion required in the next step are printed on the battery
label. If the information is unreadable, contact the battery
manufacturer.
1 CCA
2 CA
3 JIS
4 MCA
5 DIN
6 SAE
7 IEC
8 EN
Press NEXT to continue.
