EXP-803Chapter 9: Importing Data
The tester puts all test data into a le entitled user.csv, which
is saved and updated on the data card. This test data can then
be viewed and analyzed in a spreadsheet application such as
Microsoft Excel.
Importing The Data
1. Eject the data card from the tester.
2. Insert the card into a data card reader connected to your
PC.
3. Open your spreadsheet application and select File/Open.
4. In the Open dialog box, navigate to the data card in the
reader.
5. Click on the user.csv le to highlight it and select open.
Data Fields
Data for the following elds are included in the user.csv le.
These data elds will be displayed as the header row in your
spreadsheet application.
STORE ID# Entered by user
TIME Time of test
DATE Date of test
LOCATION Tested in-vehicle or out-of-vehicle
MEASURED CCA Tested cold cranking amperage
RATED CCA Inputted by user
MEASURED VOLTS Tested measured voltage
RATED VOLTS Entered by user
TEMPERATURE Fahrenheit/Centigrade
AGE Age of battery
BATTERY DECISION Good/Bad/Charge/Recharge/
Replace/Marginal/24v
USER ID User ID under which the test was
conducted
INPUT 1 Entered by user
INPUT 2 Entered by user
INPUT 3 Entered by user
STARTER VOLTS Starter voltage measured when
tested
STARTER DECISION Normal/Low Voltage/Charge/
Replace/No Start
CHARGE NL VOLTS Tested no load voltage
CHARGE LD VOLTS Tested with voltage load
CHARGE DECISION No problems/No output/Low output/
High Output
SOFTWARE VERSION Tester software version
Chapter 9: Importing Data
