23
EXP-803 Chapter 8: Printing Test Results
If you are using the tester’s internal printer, keep the clamps
connected to the battery during the printing process. After a
test the results automatically print.
NOTE: When the option TRACK CALLS is enabled, the
tester writes the results to the data card.
1. To print a second copy of the results press PRINT.
2. Press PRINT again to print the test result in the language
you selected.
Changing Printer Paper
The internal printer is shipped with a roll of thermal printing
paper installed in the paper compartment. The roll size is 2¼
inches wide by 1
7
/
8
inch in diameter. Replacement rolls are
available at most oce supply stores.
NOTE: Due to production variances some paper roll
diameters may be too large. Please remove paper
from roll to recommended 1
7
/
8
inch diameter. DO NOT
force cover to close if roll is too large.
1. To replace the paper roll unlock the printer door by gently
pressing down on the red lever.
2. Lift the printer door and remove the spent roll.
Push the lever in this direction
Paper sensor
3. Place a new roll of paper in the compartment. As the
diagram in the paper compartment indicates, the paper
feeds from the bottom of the roll.
4. Pull the paper forward so that it extends past the serrated
edge of the paper slot.
5. Close the door and make sure the lever locks securely. For
a clean tear, pull the paper along the serrated edge.
Do not pull the paper straight out of the printer.
Chapter 8: Printing Test Results
