During charging, the charger displays the charging voltage,
charging current, remaining time to charge, the charging
mode, and the amount of charge put back into the battery
in amp-hours.
Note: If you need to stop (abort) the charging session,
press the STOP button. However, you will not be able to
obtain a test code after an aborted charge.
CHARGE COMPLETION
The automatic charge session is complete when the
proper amount of charge is put back into the battery or the
remaining time to charge goes to zero. The charger will
then perform its final diagnostic tests on the battery.
When the analysis is complete, the charger will alert you
with an alarm and display the battery voltage, available
starting current in CCA, total charging time, battery
condition, and the final amount of charge put back into the
battery in amp-hours. The display will alternate between the
results and a message to press ENTER
↵↵
↵↵
↵ for the test
code. (See “Test Code Generation.”)
The alarm will sound every 30 seconds until you press the
STOP button or disconnect the charger clamps from the
battery.
TOP-OFF CHARGING
When the result is Good Battery, the charger will go into
Top-Off Mode. You have the option of stopping Top-Off
Mode by pressing the STOP button or the charger will stop
automatically when the charging current drops below
2 amps. The charger alerts you of the transition with a
message and an alarm.
During Top-Off Mode, the charger sounds an alarm every
minute and displays the charging voltage, charging current,
Top-Off Mode message, and the amount of charge put
back into the battery in amp-hours.
• 14 •
14.5V 35.5A Tmax=0:32:27
Automatic Charge AH: 4.6
14.53V 246CCA 0:00:20
Charging Aborted AH: 0.0
Analyzing Battery
........
........
....
12.82V 645CCA 0:40:36
Good Battery AH: 27.1
Press Enter For Code
GR1-120 Charging Modes: Diagnostic Fast Charge
To Next Page
