2. MANUAL CHARGE
Note: Manual Charge does not generate test codes.
2.1 CONNECT THE CHARGER TO THE BATTERY
Important: Before connecting the clamps to the battery,
turn the power switch to the OFF position and disconnect
the AC power cord from the electrical outlet
Connect the charging clamps to the battery in
accordance with all precautions and safety instructions
Do not connect either clamp to the vehicle chassis.
2.2 CONNECT TO AC POWER
Plug the charger into a dedicated, grounded 15-amp AC
outlet. Press the power switch to the ON position.
If the clamps are not making good contact to the battery
posts, the charger will ask you to check the connection.
Make sure that both jaws of the charging clamp come in
good contact with the battery post. Check Clamp
Connections will remain on the display as long as half of
one clamp is not making good contact.
If you accidentally reverse the clamp connections, the
charger will sound an alarm and display Charger Clamps
Reversed. Press the power switch to the OFF position
and reconnect the clamps.
2.3. SELECT CHARGING MODE
Use the DOWN/UP
buttons to select Manual
Charge. Press the ENTER
↵ ↵
↵ ↵
↵ button to continue.
2.4 SELECT BATTERY TYPE
Use the DOWN/UP buttons to select the battery
type: Lead Acid or AGM/Spiral. Press the ENTER
↵↵
↵↵
↵
button to continue.
2.5. SELECT CHARGE CURRENT
Use the DOWN/UP buttons to select the output
current: 10 Amp Mode, 30 Amp Mode, or 60 Amp Mode.
Press the ENTER
↵↵
↵↵
↵ button to continue.
Notes: When in doubt, start with the lowest charging rate.
If you select 60 Amp Mode, the charger will automatically
switch to 30 Amp Mode after one hour of timed or
continuous charging.
GR1-120 Charging Modes: Manual Charge
• 17 •
Mode
↑↓↑↓
↑↓↑↓
↑↓
Manual Charge
↵↵
↵↵
↵
Select Battery Type
↑↓↑↓
↑↓↑↓
↑↓
Lead Acid
↵↵
↵↵
↵
Select Charge Current
↑↓↑↓
↑↓↑↓
↑↓
10 Amp Mode
↵↵
↵↵
↵
Charger Clamps Reversed
Check Clamp Connections
GR-1 Fast Charger X4.2
(c) Midtronics, Inc. 2004
