If you connect the clamps in the wrong polarity (positive to negative or negative to positive), the tester
displays CLAMPS REVERSED! Reconnect the clamps correctly.
To make sure both sides of the clamps are gripping the terminals, rock the each clamp back and forth. A
poor connection will prevent testing, and the tester will display the message CHECK CONNECTION. If the
message reappears after you have correctly reconnected the clamps, clean the terminals and reconnect.
Setting User Preferences
Before starting your test you may want to customize the use of your analyzer by setting preferences in the
Utility Menu. The menu has settings for the display’s date and time, the contrast and backlight time, a utility
to customize printouts, among others.
To conserve the analyzer’s internal batteries, the tester will turn o after 30 seconds of inactivity.
Chapter 3: Test Preparation
