Maintenance mode
This test mode is speci cally designed for new vehicles that are stored on a compound, in a port or at the
dealer storage before delivery to the customer.
1. POWERING UP SCANNER....
2. Scan the VIN bar code
When it’s impossible to scan the VIN code press the
NEXT soft key to enter it manually.
3. Select the TEST LOCATION
TOP POST
JUMP START POST
Press the
NEXT soft key to continue.
4. Select the VEHICLE (JUMP START POST)
TOUAREG
TOUAREG V10 TDI
By selecting a vehicle the tester will use a pre-de ned compensation factor to overcome the extra
resistance caused by the JUMP START POST cable. Selecting the wrong vehicle can lead to incorrect
measurements.
Press the
NEXT soft key to continue.
5. Scan the BATTERY VIN bar code
When it’s impossible to scan the VIN code press the
NEXT soft key to select it from a pre-de ned
list.
6. Select the TEMPERATURE.
Aim the tester 2 inches (5 cm) from the sides or top of the battery case. As soon as the temperature
reading is stable the operator can press NEXT
For the next few seconds the tester will display the word
TESTING and a stopwatch while it evaluates the
battery.
Chapter 4: Battery Test
