Installing in a side-by-side combination
84
Place the appliances next to each
other so that the fronts are aligned,
leaving a gap of slightly over 40mm
between them.
Remove screws and keep them for
the next step. They are needed for
securing connecting bracket with.
The upper connecting bracket is
fitted to align both appliances in
height and depth with each other. If
one appliance stands higher than the
other, start with the higher one first.
Fit the upper connecting bracket
to the pins on the appliance and
secure it follows:
1. Secure connecting bracket in
position using the screw that you
have just unscrewed from the
appliance, and screws.
2. Now press the second appliance up
against the spacer piece on the
connecting bracket.
3. Secure connecting bracket in
position on the second appliance
using the screw that you have just
unscrewed from the appliance, and
screws. When doing so push the
appliances together slightly.
