Installing in a side-by-side combination
86
The holes for securing the
connecting bracket to have to be
pre-drilled.
 Push the connecting bracket with
cut-outs over the holders for the
wall spacers.
 Use a pen to mark the position of the
drill holes.
 Then take the connecting bracket
off again.
Drill through the panel only. Drilling
depth approx. 1mm.
 Drill the screw holes with a 3mm bit
and then file any rough edges
smooth.
 Place connecting bracket with the
horizontal long slot on the left-hand
side and secure it as follows:
1. Secure it loosely with screw.
2. Adjust the connecting bracket  until
its centre piece abuts against the
side of the second appliance.
3. Secure the connecting bracket
using screw.
4. Now tighten the loose screw and as
you do so push the right-hand
appliance up against the left-hand
appliance.
