Changing the door hinging
92
Removing the soft-close
mechanism
Click the red safety device
(supplied with the refrigeration
appliance) into place in the opening.
The safety device prevents the soft-
close mechanism and the hinge plate
from snapping shut.
Do not remove the red safety device
until instructed to do so.
Push the pin out of the door
hinge and remove it.
Move the hinged arm of the soft-
close mechanism away from the door
hinge.
Use a flat-head screwdriver to push
the tab down and pull the cover
out of the coupling.
