Changing the door hinging
93
Remove the door
Danger of injury when removing
the appliance door.
The door is not secure as soon as
the pin has been removed from the
door hinge.
The door must be held by a second
person.
Carefully pull off safety cover.
Loosen pin slightly
(approx.¼turn) until it clicks.
Now use your fingers to pull pin
right out.
Lift the door off and place it carefully
to one side.
Change the lower hinge plate
over
Pull hinge pin complete with
washer and adjusting foot upwards to
remove.
Unscrew hinge plate.
Remove cover and refit on the
opposite side.
