Changing the door hinging
94
Secure hinge plate on the opposite
side, starting with screw in the
middle at the bottom.
Then screw in the other two
screws.
Reinsert hinge pin complete with
washer and adjustable foot.
Important! The lug on the hinge pin
must point to the back again.
Changing the upper door hinge
over
Undo and remove screw on door
hinge.
Pull bearing bush out of the guide
on door hinge and refit it on the
opposite side.
Push cover off to the side.
