Servicing the drying unit
The service programs CHANGE TA
COARSE and CHANGE TA FINE are
factory pre-set to program slots 62
and 63 but can be shifted to other
program slots (see "Programming
manual / System function").
Changing the coarse filter
If CHANGE TA COARSE appears in the
display, the coarse filter needs to be
replaced.
^
Pull open the drawer to the control
box.
^
Remove the filter screen from the
drying unit.
^ Change the coarse filter. The soft
side of the filter must face the front.
^ Re-insert the metal screen at the
bottom, then press it into place at the
top.
^ Close the control box drawer.
Whenever you replace the coarse filter,
you should also re-set the counter.
To do so:
^
Select the CHANGE TA COARSE
program
^
Press the "Start" 6 button.
When the service program has finished,
the display will show a message.
^
Confirm the command üCONTINUE<
using "Start" 6.
Caring for the appliance
50
