Flush fit cooktops are only suitable
for installation in granite, marble,
tiled or solid wood worktops.
See "Building-in dimensions" to
check which cooktop can be fitted
into a glass worktop.
For all other worktop materials,
consult the worktop manufacturer
whether they can be used with a
flush-fit cooktop.
The unobstructed width of the base
unit needs to be at least as wide as
the inner worktop cut-out (see
"Building-in dimensions") so that the
cooktop is accessible from below
and the lower cabinet can be
removed for maintenance and
servicing purposes.
If the cooktop is not accessible from
below after installation, the seal
must be removed in order for the
cooktop to be taken out.
The cooktop can be installed
–
in a suitable cut-out in a granite or
marble worktop.
–
in a suitable cut-out in a tiled or solid
wood worktop with a wooden support
frame. The frame must be provided
on site, and is not supplied with the
appliance.
Installation
52
