Technical Information
30
MasterChef Ovens
Figure 4-4: Self-Clean Temperature Sensor (1) and Catalyst Vapor Outlet (2)
4.11 Oven Cavity Thermostat
Each separate oven cavity is equipped with a high-temperature thermostat
(thermal cutout). The thermostat is designed to interrupt the power in case
the temperature exceeds 680°F (360°C) during normal operation.
4.12 Self-Clean Thermostat (“P” Models Only)
Each separate oven cavity is equipped with a self-clean thermostat designed
to interrupt the power should the temperature exceed 968°F (520°C) during
the self-clean mode.
4.13 Convection Fan
The convection fan is mounted to the rear wall of the oven cavity. It
pressurizes a large volume of air in the small cavity located in the rear wall of
the oven to produce true convection.
Figure 4-5: Convection Airflow
