Technical Information
34
MasterChef Ovens
5.3 Runner Removal
5.3.1 H 39x, H 488x, H 489x
1. Remove the oven door (see Section 5.2.1).
2. Turn the two thumbscrews (Figure 5-3, Item 1) counterclockwise and remove.
3. Pull the runners (Figure 5-3, Item 2) away from the oven wall to remove.
Figure 5-3: Runner Removal (H 39x, H 488x, H 489x)
5.3.2 H 468x
1. Remove the oven door (see Section 5.2.2).
2. Pull the fastener to release the runner (see Figure 5-4).
3. Remove the runners by pulling them out of the rear of the oven (see
Figure 5-5).
Figure 5-4: Runner Release (H 468x)
Figure 5-5: Runner Removal (H 468x)
