Technical Information
58
MasterChef Ovens
7. Remove the hinge to the rear; see Figure 5-40.
8. Repeat for the other hinge.
Figure 5-40: Hinge Removal, Part 2 (H 478x)
5.35.3 H 468x
1. Remove the oven door (Section 5.2.2).
2. Remove the oven for service (Section 5.5).
3. Remove the side covers (Section 5.13).
4. Remove the screws securing the hinge(s). See Figure 5-41.
5. Remove the hinge(s).
Figure 5-41: Hinge Removal (H 468x)
