Technical Information
45
MasterChef Ovens
Figure 5-21: Safety Cover Retaining Screws
Note:
Use caution when lifting the front of the safety cover, as wiring is still
connected.
Note:
A second person is required to lift the safety cover or
to safely secure it into
a position during latch, door lock switch and/or door close switch
service/replacement.
5. Slightly lift the safety cover near the front to access the latch assembly,
as shown in Figure 5-22.
To Next Page
