Miele PT 5137 WP User Manual

2. When to clean the plinth filter
Normal operation of the dryer
The plinth filter should be cleaned
when the Clean plinth filter prompt
appears in the display.
Continuous operation of the dryer
The plinth filter should be cleaned
once a day and also when the
prompt to do so appears in the
display.
The plinth filter is located on the left
of the dryer behind the access panel.
It collects finer fluff, hair and
detergent residues which have got
through the surfaces of the fluff filters
in the door and the door opening.
^
See "Cleaning the plinth filter".
^
Press OK to delete the Clean plinth
filter prompt.
3. When to clean the grille in the
bottom right/airway
The grille should only be cleaned
when Open bottom right grille. Clean
airways appears in the display.
The air cooling vents are located in
the bottom right grille.
The cooling fins behind the grille can
become blocked by dirt particles
drawn in with the room air.
^ Always keep the area around the
tumble dryer free of dust and fluff.
This may make cleaning the bottom
right grille/airway unnecessary.
^
See "Bottom right grille/airway".
^
Press OK to delete the Open bottom
right grille. Clean airways prompt.
Cleaning and care
33

Miele PT 5137 WP Specifications

General

Door hinge	Left
Cord length	2 m
Drum volume	130 L
Control type	Buttons, Rotary
Display type	LCD
Loading type	Front-load
Certification	CE, VDE, VDE-EMC, WEEE
Drying system	Heat pump
Product color	Stainless steel
Built-in display	Yes
Reversible doors	-
Door opening angle	167 °
Appliance placement	Freestanding
Cycle time	- min
Noise level	70 dB
Drum capacity	6.5 kg
Delay start (max)	24 h
Current	10 A
Heat source	Electric
Connected load	1250 W
AC input voltage	220-230 V
AC input frequency	50 Hz
Energy consumption	- kWh
Annual energy consumption	254 kWh

Weight and Dimensions

Depth	727 mm
Width	595 mm
Height	850 mm
Weight	77000 g
Door opening diameter	410 mm
