Bottom right grille/airway
When to clean
,
The grille should only be
cleaned when Open bottom right
grille. Clean airways appears in the
display.
^
Press OK to delete the Open bottom
right grille. Clean airways prompt.
Confirm with OK.
Removing
Use the yellow lever supplied to open
the bottom right grille.
^
Insert the lever in the middle of the
gap at the top and lift it up gently
(see arrow) until the grille opens out
at the top.
^
Now remove the grille by pulling it
diagonally upwards.
Cleaning
^
Check whether the cooling fins are
clogged.
,
Danger of injury.
Do not touch the cooling fins with
your hand. You could cut yourself.
Visible clogging:
,
We recommend cleaning with a
vacuum cleaner and dusting brush,
Pass the dusting brush over the
cooling fins very lightly and
without using any pressure.
Take care not to bend or damage
the cooling fins.
^
Remove any soiling with the dusting
brush carefully and without using
any pressure.
Cleaning and care
