Electrical connection
All electrical work must be performed by a
qualified technician in accordance with ap
-
plicable codes and standards.
The machine must only be connected to the
voltage and frequency shown on the data
plate.
The machine is supplied as standard for
connection to a 208 V, 60 Hz, 20 A, 3-phase
electricity supply.
The electric heater rating is factory preset
to 24 kW (WS 5240), 30 kW (WS 5320).
The minimum suds level required for activat
-
ing the heating is 110 mm column of water.
The motor has an overload protection
switch.
Connection should be made via a suitable,
approved isolator, with an on-off switch eas-
ily accessible for servicing.
WARNING
THIS APPLIANCE MUST BE
GROUNDED !
Steam connection
Steam connection must only be undertaken
by an authorized Miele installer.
All removable outer housing parts must
be refitted after the machine has been in
-
stalled and the necessary connections
made to on-site supplies.
Installation
35
