Miele WTF 130 WPM User Manual

Cleaning and care
73
Cleaning the water inlet filter
This washer-dryer has a filter to protect
the water inlet valve. The filter in the
union in the open end of the inlet hose
should be replaced every 6 months or
so, or more often if there are frequent
interruptions to the water supply.
 First turn off the stopcock.
 Unscrew the inlet hose from the stop-
cock.
 Remove the rubber seal 1 from the
recess.
 Hold the free end of the inlet hose
downwards. Plastic filter 2 will drop
out.
 Clean the plastic filter.
 Put the filter and seal back in the re-
verse order and reconnect the hose.
 Turn on the stopcock and check the
connection is watertight. If water
drips out, tighten the connection.
The filter must be put back in place
after cleaning.

Miele WTF 130 WPM Specifications

General

Door hinge	Right
Control type	Buttons, Rotary
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Half-load	-
Drying capacity	4 kg
Washing capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (wash)	- dB
Water consumption washing per cycle	90 L
Energy consumption washing per cycle	- kWh
Water consumption washing & drying per cycle	- L

Weight and Dimensions

Depth	636 mm
Width	596 mm
Height	850 mm
