Mikro MK2000 - MRSOH - Manual Reset for High-Set Overcurrent; MRSEL - Manual Reset for Low-Set Earth-Fault

4.5 Switch Group 5
This switch group configures the operation characteristic of relay output
"START2, (SS1)".
MRSOL MRSOL - Manual Reset for Low-set Overcurrent
This switch selects or de-selects the manual resetting feature of the relay
output SS1 when activated by the low-set overcurrent start signal.
1 = Manual reset of SS1 when activated by low-set overcurrent start
signal.
0 = Auto reset of SS1 when fault is cleared.
MRSOHMRSOH - Manual Reset for High-set Overcurrent
This switch selects or de-selects the manual resetting feature of the relay
output SS1 when activated by the high-set overcurrent start signal.
1 = Manual reset of SS1 when activated by high-set overcurrent
start signal.
0 = Auto reset of SS1 when fault is cleared.
MRSELMRSEL - Manual Reset for Low-set Earth-Fault
This switch selects or de-selects the manual resetting feature of the relay
output SS1 when activated by the low-set earth-fault start signal.
1 = Manual reset of SS1 when activated by low-set earth-fault start
signal.
0 = Auto reset of SS1 when fault is cleared.
MK2000
Page 25
S1EHS1EH S1ELS1EL S1OHS1OH S1OLS1OL MRSEHMRSEH MRSELMRSEL MRSOHMRSOH MRSOLMRSOL
Default value
0 0 0 1 0 0 0 0
Default hexa-
decimal value
1 0
User setting
User hexadeci-
mal value*
* Refer to Appendix A for the corresponding hexadecimal value.
