S2EH S2EH - SS2 link to High-set Earth-Fault
This switch enables or disables the link between the SS2 output and the
high-set earth-fault trip signal.
1 = The high-set earth-fault trip signal is linked to relay output
SS2.
0 = The high-set earth-fault trip signal is not linked to relay output
SS2.
S3OLS3OL - SS3 link to Low-set Overcurrent
This switch enables or disables the link between the SS3 output and the
low-set overcurrent trip signal.
1 = The low-set phase overcurrent trip signal is linked to relay
output SS3.
0 = The low-set phase overcurrent trip signal is not linked to relay
output SS3.
S3OH S3OH - SS3 link to High-set Overcurrent
This switch enables or disables the link between the SS3 output and the
high-set overcurrent trip signal.
1 = The high-set phase overcurrent trip signal is linked to relay
output SS3.
0 = The high-set phase overcurrent trip signal is not linked to
relay output SS3.
S3EL S3EL - SS3 link to Low-set Earth-Fault
This switch enables or disables the link between the SS3 output and the
low-set earth-fault trip signal.
1 = The low-set earth-fault trip signal is linked to relay output SS3.
0 = The low-set earth-fault trip signal is not linked to relay output
SS3.
S3EH S3EH - SS3 link to High-set Earth-Fault
This switch enables or disables the link between the SS2 output and the
high-set earth-fault trip signal.
1 = The high-set earth-fault trip signal is linked to relay output
SS3.
0 = The high-set earth-fault trip signal is not linked to relay output
SS3.
