4.6 Switch Group 6
This switch group configures the operation characteristic of relay outputs
SIGNAL1(SS2) and SIGNAL2(SS3).
S2OLS2OL - SS2 link to Low-set Overcurrent
This switch enables or disables the link between the SS2 output and the
low-set overcurrent trip signal.
1 = The low-set phase overcurrent trip signal is linked to relay
output SS2.
0 = The low-set phase overcurrent trip signal is not linked to relay
output SS2.
S2OH S2OH - SS2 link to High-set Overcurrent
This switch enables or disables the link between the SS2 output and the
high-set overcurrent trip signal.
1 = The high-set phase overcurrent trip signal is linked to relay
output SS2.
0 = The high-set phase overcurrent trip signal is not linked to relay
output SS2.
S2ELS2EL - SS2 link to Low-set Earth-Fault
This switch enables or disables the link between the SS2 output and the
low-set earth-fault trip signal.
1 = The low-set earth-fault trip signal is linked to relay output SS2.
0 = The low-set earth-fault trip signal is not linked to relay output
SS2.
MK2000
Page 27
S3EHS3EH S3ELS3EL S3OHS3OH S3OLS3OL S2EHS2EH S2ELS2EL S2OHS2OH S20LS20L
Default value
1 1 0 0 0 0 1 1
Default hexadeci-
mal value
C 3
User setting
User hexadecimal
value*
* Refer to appendix A for the corresponding hexadecimal value.
