Mikro MK2000 - MRSEH - Manual Reset for High-Set Earth-Fault; S1 OL - SS1 Link to Low-Set Overcurrent; S1 OH - SS1 Link to High-Set Overcurrent; S1 EL - SS1 Link to Low-Set Earth-Fault

MRSEH MRSEH - Manual Reset for High-set Earth-Fault
This switch selects or de-selects the manual resetting feature of the relay
output SS1 when activated by the high-set earth-fault start signal.
1 = Manual reset of SS1 when activated by high-set earth-fault start
signal.
0 = Auto reset of SS1 when fault is cleared.
S1OLS1OL - SS1 link to Low-set Overcurrent
This switch enables or disables the link between the SS1 output and the
low-set overcurrent start signal.
1 = The low-set phase overcurrent start signal is linked to relay
output SS1.
0 = The low-set phase overcurrent start signal is not linked to relay
output SS1.
S1OH S1OH - SS1 link to High-set Overcurrent
This switch enables or disables the link between the SS1 output and the
high-set overcurrent start signal.
1 = The high-set phase overcurrent start signal is linked to relay
output SS1.
0 = The high-set phase overcurrent start signal is not linked to relay
output SS1.
S1EL S1EL - SS1 link to Low-set Earth-Fault
This switch enables or disables the link between the SS1 output and the
low-set earth-fault start signal.
1 = The low-set earth-fault start signal is linked to relay output SS1.
0 = The low-set earth-fault start signal is not linked to relay output
SS1.
S1EH S1EH - SS1 link to High-set Earth-Fault
This switch enables or disables the link between the SS1 output and the
high-set earth-fault start signal.
1 = The high-set earth-fault start signal is linked to relay output SS1.
0 = The high-set earth-fault start signal is not linked to relay output
SS1.
