Parameter, display Description Value range
Curve Dynamic range 1 … 6
Splash Sensitivity Touch sensitivity of the hi-hat –4 … 4
Local To determine, which MIDI signals are processed
(connected pads or external MIDI sequencer)
ON/OFF
MIDI OUT Format Determines the MIDI output format intern/GM
1. Press the [utility] button until the display shows the current touch sensitivity in format
‘Exx’.
2. Press the button of the pad whose touch sensitivity you want to change. Alternatively,
you can directly activate the pad by playing it.
3. Adjust the touch sensitivity using the [–]/[+] button.
4. Repeat steps 2 to 3 to adjust the touch sensitivity of the other pads as desired.
5. Press [utility] to jump to the next parameter.
Touch sensitivity of the pads
Operation
e-drum module
32
