1. Press the [utility] button until the display shows the current touch sensitivity of the Rim
triggers in format ‘rEx’.
2. Activate the crash or ride cymbal, or the snare by keystroke or direct playing.
3. Adjust the Rim sensitivity using the [–]/[+] button.
4. Repeat steps 2 to 3 to adjust all rim triggers as desired.
5. Press [utility] to jump to the next parameter.
If you select a pad without rim trigger the display shows the value ‘rE-’ and you can't
make any changes.
When several pads are mounted on the same rack, vibrations may be transferred to other pads
and, thus, unwanted sounds are triggered when striking a pad. This crosstalk can be prevented
by the temporary suppression of the trigger signal.
Rim sensitivity
Crosstalk
Operation
MPS-400
33
