9-5. Changing Oil
Complete Parts List available at www.MillerWelds.com
OM-267212 Page 30
8-3. Servicing Air Cleaner
Kohler 17 690 01 Rev E
! Stop engine. Let cool
NOTICE Do not run engine with-
out air cleaner element or with dirty
element.
1 Screw
2 Foam Element
Inspect foam element. If element is
damaged, replace. If element is
clogged, wash foam element with
soap and water solution. Allow to air
dry completely.
Do not wring out foam element,
this could cause it to tear.
Oil foam element using clean en-
gine oil. Squeeze out excess oil.
The engine will smoke if excess oil
remains.
2
1
8-4. Changing Fuel Filter
804 081-B
! Stop engine. Close fuel
valve. Let cool.
! After servicing, start engine
and check for fuel leaks.
Stop engine, close fuel valve,
tighten connections as ne-
cessary, and wipe up spilled
fuel.
1 Fuel Filter
Locate fuel filter below fuel tank.
Release hose clamps and remove
filter. Replace filter . Ensure flow ar-
row points towards carburetor.
1
Tools Needed:
8-5. Changing Oil
Change oil while engine is
warm. Make sure engine is
level when filling, checking,
and changing the oil.
1 Oil Drain Plug
2 Oil Fill/Check Plug
Remove the oil drain plug and oil fill/
check plug. Be sure to allow ample
time for oil to drain completely.
Reinstall drain plug and tighten to
13 ft lb (17.6 N⋅m).
Fill crankcase with proper amount
and viscosity of oil according to
maintenance
label in Section 8-2.
Reinstall oil fill/check plug.
1
Tools Needed:
1
2
2
Kohler 17 690 01 Rev E
plug. Be sure to allow ample time for oil to
To Next Page
