TM-273245 Page 34 S-74 MPa Plus
9-3. Location Of Circuit Boards
1 Motor Board PC1
(See Section 9-4)
2 User Interface Board PC2
(See Section 9-7)
3 14 Pin Filter Board PC5
(See Section 9-9)
4 Trigger Filter Board PC8
(See Section 9-11)
246 913-C
2
1
3
4
