TM-273245 Page 41S-74 MPa Plus
Notes
16 Gauge (.063 in.)
22 Gauge (.031 in.)
24 Gauge (.025 in.)
20 Gauge (.037 in.)
18 Gauge (.050 in.)
14 Gauge (.078 in.)
1/8 in. (.125 in.)
3/16 in. (.188 in.)
1/4 in. (.25 in.)
5/16 in. (.313 in.)
3/8 in. (.375 in.)
1/2 in. (.5 in.)
MATERIAL THICKNESS REFERENCE CHART
