TM-273245 Page 46 S-74 MPa Plus

Receptacle ValuePin

RC21 1 Gun motor 0−24 volts DC reference to RC21−2

2 Gun motor 24 volts DC

3 Gun motor tach reference +5 volts DC

4 Gun motor tach common

5 Gun motor tach 0 or 5 volts DC (PC1 motor control board RC1−1 to RC1−16)

6 Push-pull gun trigger +15 volts DC

7 Push-pull gun trigger 15 volts DC when push-pull gun is triggered

8 Gun command reference +5 volts DC

9 Gun command common

10 Gun command pot 0 − 5 volts DC reference to RC21−8

11 Gun sense 2.7V for AlumaPro Plus reference to RC21−14

12 RS485A

13 RS485B

14 Gun command common

RC100 1 Chassis ground

. No testing required for remaining plugs and receptacles.
