CHAPTER 7 – 7200 CNC OPERATION
o Spindle CCW button – starts spindle in counter-clockwise direction
provided there is a programmed spindle rpm.
mergency stop buttons lock down when pressed and
st be released for drives to
or program
o Spindle STOP button – stops spindle rotation.
9) EMERGENCY STOP button – Disables machine motion, control enable, and
axis waylube oiler. E
must be rotated to release.
10) ENABLE button – When pressed and released it enables axis and spindle
drives. All Emergency stop and limit switches mu
enable.
11) Alphanumeric keypads – used to enter characters in MDI mode
mode.
12) Function keypad – used to select machine functions that are shown along the
bottom of the operator’s panel display.
43
