CHAPTER 8 – PARTS LISTS AND DRAWINGS
71
Parts list for Guarding
no. Description Q'ty Remark #
Item Part
1 E-ARFC-70041-01 Cover 1
2 E-ARFC-70040-01 Side door cover 1
3 E-ARFC-70039-01 Spindle guard 1
4 E-ARFC-70037-01 Left guard 1
5 E-ARFC-70038-01 Plate 1
6 E-ARFC-70030-01 Plate 1
7 E-ARFC-70029-01 Left bracket 1
8 E-ARFC-70050-01 Side guard 1
9 E-ARFC-70049-01 Left guard 1
10 E-ARFC-70062-01 Cover 1
11 E-ARFC-70036-01 Side bracket 1
12 E-ARFC-70016-01 Top bracket 1
13 E-ARFC-70018-01 Plate 2
14 E-ARFC-70034-01 Rear top cover 1
15 E-ARFC-70028-01 Rear guard 1
16 E-ARFC-70027-01 Rear guard 1
17 E-ARFC-70026-01 Rear right guard 1
18 E-ARFC-70080-01 Plate 1
19 E-ARFC-70008-01 Right bracket 1
20 E-ARFC-70057-01 Top bracket 1
21 E-ARFC-70061-01 Top bracket 1
22 E-ARFC-70023-01 Right guard 1
23 E-ARFC-70025-01 Plate 1
24 E-ARFC-70024-01 Door cover 1
25 E-ARFC-94023-01 Z-axis cable carrier(L=2000) 1 For length 750mm
26 E-ARFC-94046-01 Fixing plate 1
27 E-ARFC-94021-01 X-axis cable carrier 1
SQ301-II-KR150
-1030L(NO.8)
28 E-ARFC-70056-01 Fixing bracket 1
29 E-ARFC-70054-01 Fixing bracket 1
30 E-ARFC-70052-01 Fixing plate 1
31 E-ARFC-70047-01 Filtration plate 1
32 E-ARFC-70045-01 Coolant tank 1
33 Roller wheel 1
34 E-ARFC-70015-01 Front bracket 1
35 E-ARFC-70014-01 Fixing bracket 1
36 E-ARFC-70013-01 Fixing bracket 1
37 E-ARFC-70012-01 Fixing bracket 1
38 E-ARFC-70048-01 Cover 2
To Next Page
