3.1.1.1 Guards and Related Components
BNUUUH01.R09 0000399322 A.5 A.26 A.9 11/4/21 11:27 AM Released
Examine these items. If an item is damaged, missing, or has the wrong setting, correct this
discrepancy immediately to prevent injury.
Table 1. Guards and Related Components
Mark
Do this each
Component
More Data
1 2
3
4
5
6
x
day* guards, covers Speak to your dealer or Milnor for replacement
components.
x
day* safety placards
x
200 hours fasteners Fasteners must be tight.
x
200 hours anchor bolts and grout Grout must be good. Bolts must be tight.
x
day* door interlock If the machine operates with the door open:
• Immediately remove power.
• Do not permit operation.
• Speak to your dealer or Milnor.
x
day* emergency stop button
(optional on some washer-
extractors)
See Section 3.2.6 , page 29. Do a test of the control.
3.1.1.2 Filters, Screens, and Sensitive Components
BNUUUH01.R10 0000399352 A.5 A.26 A.19 11/16/21 10:29 AM Released
Remove contamination from these items to prevent damage and unsatisfactory
performance.
Table 2. Filters, Screens, and Sensitive Components
Mark
Do this each
Component More Data. See also Section 3.1.2 , page 16
1 2 3 4
5 6
x
40 to 60 hours inverter fans, vents, filters See Figure 9, page 24 . Keep good air flow.
x
600 hours
motors
Keep good air flow.
x
2400 hours entire machine Remove excessive dust and dirt.
x
day* chemical inlet areas Some chemical supplies that stay on machine surfaces
will cause corrosion damage. See Section 3.2.3 , page
24 and Section 3.1.2 , page 16. See also, Section 2.2 ,
page 9 for background information.
x
200 hours strainer(s) for air inlet See Figure 15, page 27
x
2400 hours water inlet strainers if sup-
plied by others
Remove strainers from incoming water lines and flush
with water.
x
2400 hours strainer in water regulator
for optional supply injec-
tor and pumped chemicals
on some models.
See Figure 11, page 25
x
200 hours strainer for steam inlet.
(Steam is optional on
some models.)
See Figure 14, page 27
Routine Maintenance
