Milnor 36021 - Figure 12 Air Tube for the Water Level Sensor. These Are Examples. Your Ma- Chine Can Look Different; Figure 13 Water Pressure Regulator for Chemical Flush. These Are Examples

26
Pellerin Milnor Corporation
Figure 12. Air Tube for the Water Level Sensor. These are examples. Your machine can look
different.
30022T5E Washer-extractor
42044SP2 Washer-extractor
36030F8_ Washer-extractor
Legend
1...Level switches
2...Pressure transducer
3...Air tube. See caution state-
ment below.
4...Air chamber
30022V6J Washer-extractor
Figure 13. Water Pressure Regulator for Chemical Flush. These are examples. Your machine can
look different.
64050E6N Washer-extractor
76039CBW
®
Tunnel Washer
Legend
1...Water pressure regulator
2...Water pressure gauge
3...See caution statement below.
Remove plug to remove
strainer.
