Milnor 36021 - Figure 2 Incorrect Configurations that Let the Chemical Supply Go in the Ma

Pellerin Milnor Corporation 19
Figure 2. Incorrect Configurations That Let the Chemical Supply Go In the Machine by a Siphon
Schematic Views
Legend
P...Pump
T...Chemical tank
S...The siphon occurs above here. Liquid in the gray parts of the chemical tube and tank can go in the machine.
Important Installation Precautions
