Pellerin Milnor Corporation
plumber the person(s) or contractor licensed or otherwise accepted by the local jurisdiction to
perform the plumbing work described herein, and qualified to do so.
electrician the person(s) or contractor licensed or otherwise accepted by the local jurisdiction
to perform the electrical work described herein, and qualified to do so.
chemical supplier the person(s) or contractor with detailed knowledge of 1) the machine con-
troller configuration and operation, and 2) the pumped chemical delivery system, if such a
system is to be used.
Notices
BNWUUI04.R03 0000255231 C.4 C.2 A.7 1/2/20, 2:19 PM Released
Qualified Personnel Only — Do not attempt to connect utilities to the machine unless
you are a plumber, electrician, or chemical supplier, as defined above.
Machine Must Be Anchored — Utility connections are to be made only after the ma-
chine has been anchored. See BNWUUI03 “Handling a Washer-extractor from Delivery to Final
Location.”
Other Tasks — This document and the documents it references address common tasks that
the plumber, electrician, and chemical supplier will perform. Other tasks, not explained here, can
be needed. Information about these tasks is usually provided by the dealer, the Milnor
®
Applica-
tions Engineering department, or the Milnor
®
Service department An example is electrical inter-
facing with a remote Mildata
®
data collection system.
Utility Requirements and Related Information
BNWUUI04.R05 0000255583 C.4 C.2 A.12 1/2/20, 2:19 PM Released
Type of Information Value or Where to Find
equipment list showing
model and options
purchased
For the dealer, see the order acknowledgement.
plumbing connection fitting
types, sizes, and locations
See the standard and options dimensional drawings for your mod-
el located at the back of the installation manual.
water pressure range
10 – 75 psi (69 – 531 kPa) required
Cv value See the specification sheet for your model available online at:
https://www.milnor.com/specification-sheets/. The Cv value as-
sists the piping designer in determining flow rates and pressures.
steam pressure range
30 – 115 psi (207 – 793 kPa) required, if applicable
compressed air pressure
range
85 – 110 psi (586 – 758 kPa) required, if applicable
specified voltage See the machine nameplate or the order acknowledgement.
Installation Procedures
