(7) Is there any data or dirt in the
unprintable area?
The area around the register marks (from the corners of the register marks
to an area equal to the length of the register marks) is an unprintable area.
Ensure that no data is printed in this area and it remains free from dirt.
Incorrect register mark detection or register mark reading error could
occur.
(8) Is the length of one side of the
register marks appropriate in
relation to the distance between
the register marks?
A
Less than
200
50mm
1000
2000
3000
5000
or more
B
4mm~
8mm~
15mm~
25mm~
35mm~
40mm~
1
st
point
2
nd
point
Mark Form: Type1
Mark Form: Type2
