Chapter 5 Using the XY Slitter
124
X Cutter
l
Method for securing the X cutter
Raise the X cutter lever to secure the cutter.
l
Method for mounting the X cutter
Insert the X cutter groove onto the L-shaped slide rail.
l
Unused X cutter
• Slide out the unused X cutter, or move it away from the media and secure it by raising the lever.
If you start printing with the lever being lowered (unsecured), the X cutter may hit the XY
carriage and result in damage.
